Gasketed Plate Heat Exchanger

Our gasketed plate heat exchangers combine passion, scientific curiosity and technological expertise. The facts: High efficiency at low operating costs, versatile application possibilities with lower investment costs and maximum flexibility. Our efforts to continuously develop the gasketed plate heat exchanger-series further are aimed at meeting your thermodynamic and hydraulic performance needs and to ensure maximum economic efficiency.
Our gasketed plate heat exchangers combine passion, scientific curiosity and technological expertise. The facts: High efficiency at low operating costs, versatile application possibilities with lower investment costs and maximum flexibility. Our efforts to continuously develop the gasketed plate heat exchanger-series further are aimed at meeting your thermodynamic and hydraulic performance needs and to ensure maximum economic efficiency.

Gasketed Plate Heat Exchanger

Our Product series at a glance

Filter products:
Design Pressure (Bar (g))
HPL
HPL
Design Pressure (Bar (g))
0
63
-5
37.5
80
  • innovative semi-welded solution for industrial and commercial heat pumps
  • highest efficiency thanks to highest turbulence
  • extremely high pressure resistance up to 63 bar(g) design pressure on welded side
  • high reliability for critical media on welded side
NT
NT
Design Pressure (Bar (g))
-1
28
-5
37.5
80
  • leading technology for all applications
  • Tailor-made and flexible solutions for special requirements
  • suitable for small to very large volume flows and duties with connection sizes ranging from DN25 to DN500 (1" to 20") and different plate lengths
  • extensive range of plate materials also including titanium-palladium and special alloys such as C-276 or 254 SMO
  • large choice of gasket materials with high temperature resistance, good chemical resistance or food approval
NX
NX
Design Pressure (Bar (g))
-1
30
-5
37.5
80
  • high performance e.g. for district heating and cooling systems
  • cost-efficient data center cooling solutions
  • suitable for demanding tasks with involving high pressures, small temperature differences and high NTU
LWC
LWC
Design Pressure (Bar (g))
-1
32
-5
37.5
80
  • semi-welded solution for demanding applications with critical media
  • laser-welded flow channels for higher process reliability, pressure resistance and endurance
  • gasketed flow channels for easy maintenance with cleaning access
  • flexible. cost-saving & compact design
NP
NP
Design Pressure (Bar (g))
0
32
-5
37.5
80
  • peak performance for cold supply in high-rise buildings or data centers and district cooling applications
  • perfect fit for extremely low temperature differences and very high NTU values
  • purely gasketed PHE with highest pressure resistance up to 32 bar(g) design pressure
NL
NL
Design Pressure (Bar (g))
-1
26
-5
37.5
80
  • ideal for fluids with higher viscosity as well as for shear-sensitive media thanks to larger flow channel
  • extended service life due to larger corrugation depth, which improves the flow and reduces the tendency to clog up
  • suitable for media that contain small particles/solids
  • gentle product handling and reduced pressure loss for mid-size volume flows
NW
NW
Design Pressure (Bar (g))
-0.1
10
-5
37.5
80
  • developed for media containing particles & solids e.g. in bioethanol production or wastewater treatment
  • turbulence promotes heat transfer and the self-cleaning effect leading to longer service life
  • thanks to minimal pressure loss, even with highly viscous media, operating cost are kept low
  • herringbone pattern with max. flow channel for increased pressure resistance and efficiency compared to free-flow PHE
NF
NF
Design Pressure (Bar (g))
-1
12
-5
37.5
80
  • free flow for fibre- and solid-bearing media e.g. in sugar or paper industry
  • blockage-free operation thanks to a real free-flow channel of constant width
  • thanks to higher efficiency and thus low investment & operating costs as well as little space requirements the alternative to shell and tube or spiral heat exchangers
ND
ND
Design Pressure (Bar (g))
-1
18
-5
37.5
80
  • plate duo playing it completely safe
  • effective and low maintenance double-wall solution
  • high production security with low risk of intermixture of incompatible media
  • fulfills regulations for potable water applications on- and off-shore
NH
NH
Design Pressure (Bar (g))
-0.6
28
-5
37.5
80
  • perfect solution for demanding applications requiring increased pressure resistance as well as highly resistant plate material e.g. in the oil & gas production
  • suitable for large volume flows
  • innovative plate and gasket design
NC/NA/NG/NQ
NC/NA/NG/NQ
Design Pressure (Bar (g))
-1
32
-5
37.5
80
  • performance is independently certified by AHRI according to AHRI400 standard
Loading

Gasketed Plate Heat Exchanger

IN ADDITION TO THESE COMMON APPLICATIONS, OUR GASKETED PLATE HEAT EXCHANGERS ARE ALSO SUITABLE FOR:

  • chemical process cooling
  • media containing fibres and solids (e.g., in the sugar and paper industry)
  • highly viscous media (e.g., dairy and other food products)
  • healthy drinking water treatment and purification
  • secure cooling for power plants with river or seawater
  • demanding climate control solutions (e.g., for data centres)
  • condensation or evaporation (e.g.,in refrigeration, sugar or chemical industries)
